Details
The all new SCOTT Addict 10 was designed from the ground up with those longer days in mind. With geometry that is less focused on racing and more on enduring, this bike is yearning to eat up some miles!
KEY FEATURES
- Addict Disc HMF Carbon Frame
- Addict HMF Carbon Fork
- SRAM RIVAL AXS Disc 24 Speed
- Syncros RP2.0 Disc Wheels
- Schwalbe ONE Tires
- Syncros Carbon/Alloy Parts
XXS/47 | XS/49 | S/52 | M/54 | L/56 | XL/58 | XXL/61 | |
---|---|---|---|---|---|---|---|
A. Reach | 376.3 mm | 383.2 mm | 387.0 mm | 390.9 mm | 394.3 mm | 389.6 mm | 406.6 mm |
B. Stack | 517.8 mm | 529.1 mm | 551.6 mm | 572.4 mm | 593.3 mm | 613.6 mm | 632.7 mm |
C. Standover | 732.0 mm | 747.0 mm | 775.0 mm | 790.0 mm | 812.0 mm | 835.0 mm | 848.0 mm |
D. Effective Top Tube | 515.0 mm | 525.0 mm | 540.0 mm | 555.0 mm | 570.0 mm | 585.0 mm | 600.0 mm |
E. Head Tube Angle | 70.5 ° | 71.0 ° | 72.0 ° | 72.5 ° | 73.0 ° | 73.3 ° | 73.3 ° |
F. Head Tube Length | 95.0 mm | 105.0 mm | 125.0 mm | 145.0 mm | 165.0 mm | 185.0 mm | 205.0 mm |
G. Seat Tube Angle | 75.0 ° | 75.0 ° | 74.5 ° | 74.0 ° | 73.5 ° | 73.1 ° | 73.0 ° |
H. Seat Tube Length | 455.0 mm | 475.0 mm | 505.0 mm | 525.0 mm | 545.0 mm | 565.0 mm | 580.0 mm |
I. Bottom Bracket Height | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm |
J. Bottom Bracket Drop | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm |
M. Wheelbase | 996.7 mm | 1,003.0 mm | 1,005.0 mm | 1,010.6 mm | 1,015.4 mm | 1,022.8 mm | 1,036.5 mm |
O. Chainstay Length | 420.0 mm | 420.0 mm | 420.0 mm | 420.0 mm | 420.0 mm | 420.0 mm | 420.0 mm |
Stem Length | 73.0 mm | 83.0 mm | 93.0 mm | 103.0 mm | 103.0 mm | 113.0 mm | 113.0 mm |
Bottom Bracket to Top Tube Center | 415.0 mm | 435.0 mm | 465.0 mm | 485.0 mm | 505.0 mm | 525.0 mm | 540.0 mm |
Specs
Frame |
Addict Disc HMF Carbon Endurance geometry / Replaceable Derailleur Hanger Internal cable routing Syncros fender kit ready |
---|---|
Fork |
Addict HMF Disc 1 1/4"-1 1/2" Eccentric Carbon steerer |
Wheels |
Syncros RP2.0 Disc 28 Front / 28 Rear Syncros Axle w/Removable Lever with Tool |
Tires | Schwalbe ONE Fold, 700c x 32 |
Bottom Bracket | SRAM DUB PF Road 86.5 |
Crankset | SRAM Rival Crankset |
Chainrings | 46/33T |
Shifters | SRAM Rival eTap AXS HRD |
Front Derailleur | SRAM Rival eTap AXS |
Rear Derailleur | SRAM Rival eTap AXS |
Cassette/Freewheel | SRAM Rival XG1250, 10-36 |
Chain | SRAM Rival |
Brakes | SRAM Rival eTap AXS HRD Shift-Brake System / Flatmount |
Rotors | SRAM Paceline rotor 160/F and 160/R |
Handlebars | Syncros Creston 2.0 Compact, Alloy 31.8mm |
Stem | Syncros RR2.0, 1 1/4", four-bolt, 31.8mm |
Headset | Acros AIF-1112 |
Seatpost | Syncros Duncan 1.0, 27.2/350mm |
Saddle | Syncros Tofino Regular 2.0 Channel |
Accessories & Extras | SRAM AXS Powerpack, SRAM TyreWiz, Syncros Eco Sealant Transport Axle |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Carbon Black / 54cm | 192820603179 | 286423054 | 5681 |
Carbon Black / 56cm | 192820603186 | 286423056 | 5785 |
